Home > Press > The Chemnitz University of Technology selects JPK's NanoWizard AFM system for the characterization of polymeric and biological materials

Professor Robert Magerle (right) watches Eike-Christian Spitzner working with the
JPK NanoWizard AFM
Professor Robert Magerle (right) watches Eike-Christian Spitzner working with the JPK NanoWizard AFM

Abstract:
JPK Instruments, a world-leading manufacturer of nanoanalytic instrumentation for research in life sciences and soft matter, is pleased to report on the research work from the Chemical Physics group of Professor Robert Magerle of the Chemnitz University of Technology.

The Chemnitz University of Technology selects JPK's NanoWizard AFM system for the characterization of polymeric and biological materials

Berlin, Germany | Posted on August 3rd, 2011

The Chemical Physics Group is part of the Faculty of Natural Sciences. The main research topic is the study of the structure and properties of polymeric materials. Within this, Professor Magerle's goals are to learn about structure, structure-formation processes and properties of both polymeric and biological materials (bone and other collagen based materials) on the nanometer scale. One general lines of research is imaging structure formation processes in these materials in their native state, where the materials are soft or even fluid.

The discovery of new phenomena on the nanometer scale is vital for progress in research and technology. The use of atomic force microscopy, AFM, provides unique opportunities for the study of soft materials including polymers, polymer melts and solutions. It is also well suited for the study of biological materials. For this purpose, Professor Magerle's group developed a microtensile testing setup that allows imaging with AFM local deformation processes in thin polymer films. With this new setup the group discovered locally auxetic behaviour in a thin film of elastomeric polypropylene. This unusual property, which causes the material to expand when it is stretched, appears to be an intrinsic property of certain semi-crystalline polymers.

Having used a variety of different types of AFM in his earlier work, Professor Magerle saw many advantages in moving to the JPK NanoWizard® AFM. Speaking on this, Professor Magerle said "We have chosen the NanoWizard® AFM since it is a tip-scanning system and allows us to place our home-built microtensile testing setup precisely below the AFM tip. JPK has provided us with a custom-built base-plate with an extra cut-out in the center so we could mount our microtensile testing setup. Another aspect I like about the NanoWizard® is its solid mechanical design with a tripod. It is very stable with very little thermal drift. Furthermore, the NanoWizard® can be combined with an optical microscope which we intend to use in future projects."

Collaboration with users is very important to JPK. As Torsten Jähnke, JPK's Chief Technical Officer, says "Working closely with our users enables us to see what new developments might be incorporated in the design of future instruments. Right from day one when we started the company twelve years ago, we have made it the company's policy to closely work with our users and to listen to their feedback as to what they thought of both the hardware and software aspects of our instruments."

JPK develops, engineers and manufactures instrumentation in Germany to the world-recognized standards of German precision engineering, quality and functionality. For further details of the ForceRobot® 300 and other products in the JPK family of nanoscale characterization instrumentation, please visit the JPK web site (www.jpk.com) or Facebook (www.jpk.com/facebook).

####

About JPK Instruments
JPK Instruments AG is a world-leading manufacturer of nanoanalytic instruments - particularly atomic force microscope (AFM) systems and optical tweezers - for a broad range of applications reaching from soft matter physics to nano-optics, from surface chemistry to cell and molecular biology. From its earliest days applying atomic force microscope (AFM) technology, JPK has recognized the opportunities provided by nanotechnology for transforming life sciences and soft matter research. This focus has driven JPK’s success in uniting the worlds of nanotechnology tools and life science applications by offering cutting-edge technology and unique applications expertise. Headquartered in Berlin and with direct operations in Dresden, Cambridge (UK), Singapore, Tokyo (Japan) and Paris (France), JPK maintains a global network of distributors and support centers and provides on the spot applications and service support to an ever-growing community of researchers.

For further information, please contact JPK direct or their marketing partners, NetDyaLog, who will also provide high resolution images for your use.

For more information, please click here

Contacts:
Jezz Leckenby
NetDyaLog Limited
T: +44 (0) 1799 521881
M: +44 (0) 7843 012997

or
Claudia Boettcher
JPK Instruments
T: +49 (0) 30 5331 12070

Copyright © JPK Instruments AG
