Home > Press > Scientists provide new guideline for synthesis of fullerene electron acceptors

Fullerene derivatives have been widely used as electron acceptors in organic/polymer solar cells and perovskite solar cells. To investigate the stereomeric effects of fullerene on the photovoltaic performance, two stereomers of the bisadduct analogues of [6,6]-phenyl-C71-butyric acid methyl ester (bisPC71BM) were isolated and blended with poly(3-hexylthiophene) (P3HT) for fabricating polymer solar cells. Although both trans- and cis-bisPC71BM showed similar spectrometric and electronic properties, a photovoltaic discrepancy resulted from the difference in their molecular packing. Accordingly, the guidelines for designing an efficient electron acceptor should be supplemented, and the stereomeric effect should be envisaged in addition to the fullerene core, type of functional group, and number of addends and their addition positions. The cover picture shows the structures of the trans- and cis-bisPC71BM molecules as well as the polymer solar cells.

©Science China Press
Fullerene derivatives have been widely used as electron acceptors in organic/polymer solar cells and perovskite solar cells. To investigate the stereomeric effects of fullerene on the photovoltaic performance, two stereomers of the bisadduct analogues of [6,6]-phenyl-C71-butyric acid methyl ester (bisPC71BM) were isolated and blended with poly(3-hexylthiophene) (P3HT) for fabricating polymer solar cells. Although both trans- and cis-bisPC71BM showed similar spectrometric and electronic properties, a photovoltaic discrepancy resulted from the difference in their molecular packing. Accordingly, the guidelines for designing an efficient electron acceptor should be supplemented, and the stereomeric effect should be envisaged in addition to the fullerene core, type of functional group, and number of addends and their addition positions. The cover picture shows the structures of the trans- and cis-bisPC71BM molecules as well as the polymer solar cells.

©Science China Press

Abstract:
Organic/polymer solar cells represent the most important direction for green energy in the future. Fullerene electron acceptors have been widely used in organic/polymer solar cells as well as perovskite solar cells. A recent study reveals that the photovoltaic performance can be influenced by fullerene stereomer, implies that the stereomeric effect should be envisaged if new fullerene derivative was designed as electron acceptor.

Scientists provide new guideline for synthesis of fullerene electron acceptors

Beijing, China | Posted on January 28th, 2016

The paper was reported in Science Bulletin 2016(2) issue, entitled "Stereomeric effects of bisPC71BM on polymer solar cell performance" and "Theoretical insight into the stereometric effect of bisPC71BM on polymer cell performance"by Su-Yuan Xie and Yi Zhao et al from Xiamen University. The authors synthesized and separated two stereomers of bisadduct analogues of [6,6]-phenyl-C71-butyric acid methyl ester (bisPC71BM). Although both isomers have the same spectrometric and electronic properties, photovoltaic discrepancy was shown. Supported by both crystallographic and theoretical analyses, the stereomer-dependent photovoltaic performance was revealed to result from discrepancy of molecular packing.

Up to now, fullerene derivatives [6,6]-phenyl-C61-butyric acid methyl ester (PC61BM) and its C70 analogue PC71BM still dominate the fullerene acceptors, which were developed 20 years ago. Due to their excellent properties such as high electron mobility, strong light absorption, good solubility, high electron affinity and good compatibility with donor materials, PC61BM and PC71BM are the best electron acceptors synthesized so far. In the past 20 years, great efforts have been made to develop new electron acceptors superior to PC61BM/PC71BM. However, it is more difficult to do something than we can imagine. First of all, we should choose suitable fullerene core. Then, the following factors should be taken into consideration in turn: the type of functional groups attached to fullerene core, the number of addends and their addition position, etc. Although researchers never cease to synthesize novel fullerene acceptors according to these guidelines and hundreds of fullerene acceptors have been synthesized in the past 20 years, the photovoltaic performance of these fullerene acceptors is still not good enough.

In principle, when designing novel fullerene acceptors, if we can consider these factors such as fullerene core, the type of functional groups attached to fullerene core, the number of addends and their addition position in turn, we can obtain fullerene acceptors with specific photovoltaic performance. Therefore, after 20 years of hard work, researchers could have developed fullerene acceptors superior to PCBM. However, this is not the case in reality. So, are there any other factors that we should take into consideration when designing novel fullerene acceptors?

It should be noted that the synthesized fullerene derivatives have stereomers even though considering these guidelines such as fullerene core, the type of functional groups attached to fullerene core, the number of addends and their addition position. Do these fullerene stereomers have different photovoltaic performance? With this question, two stereomers of bisadduct analogues of PC71BM (bisPC71BM) with cis or trans configuration were designed and used as electron acceptors in polymer solar cells. It is demonstrated that the two stereomers have very similar LUMO energy levels and light absorption as well as other properties. However, polymer solar cells based on the two stereomers exhibited different photovoltaic performance (compared with cis-bisPC71BM, the trans-bisPC71BM has an efficiency about 7% for improving power conversion efficiency of polymer solar cells). Further investigation shows that the difference in crystal packing pattern of bisPC71BM isomers is the main cause of their divergent photovoltaic performance. A theoretical investigation also reveals that the molecular packing of isomers affect the electron mobility and exciton dissociation efficiency. Thus, both experimental and theoretical investigations demonstrate that the stereometric effects of fullerene acceptors have an important impact on solar cell performance. Therefore, a new guideline for designing efficient electron acceptor was proposed, which has long been neglected.

The main difficulty of this experiment is the synthesis and separation of bisPC71BM stereomers. The two stereomers were separated by multistage high-performance liquid chromatography (HPLC) technique from 28 isomers. The molecular structures of them were unambiguously determined by X-ray single-crystal analysis to determine their crystal structure and molecular packing. Bulk-heterojunction solar cells using poly (3-hexylthiophene) (P3HT) as donor and bisPC71BM stereomer as acceptor were fabricated and their photovoltaic performance were evaluated to investigate the stereomeric effects of bisPC71BM on polymer solar cell performance. Theoretical investigation was performed by combination methods of electronic structure calculations and Marcus theory, with emphasis on employing independent structural parameters to predict measurable variables in experiment. By comparing theoretical calculation results with experimental data, theoretical investigation reveals the mechanism behind the different photophysical processes caused by stereomers and proposes possible ways to further enhance the photovoltaic performance. Therefore, a new guideline on stereomeric effects of fullerene derivative for designing efficient electron acceptor should be taken into consideration, which makes it possible for us to fully consider the factors that affect photovoltaic performance. It also provides new ideas for developing excellent electron acceptors with high electron mobility, strong light absorption, good solubility, high electron affinity and good compatibility with donor materials.

###

This work was supported by National Basic Research 973 Program of China (2014CB845601), National Nature Science Foundation of China (U1205111, 21390390, 51572231, and 51502252).

####

For more information, please click here

Contacts:
Xie Su-Yuan

Copyright © Science China Press

If you have a comment, please Contact us.

Issuers of news releases, not 7th Wave, Inc. or Nanotechnology Now, are solely responsible for the accuracy of the content.

Bookmark:
Delicious Digg Newsvine Google Yahoo Reddit Magnoliacom Furl Facebook

Related Links

See the article:

2. Wen-Peng Wu, Lin-Long Deng, Xiang Li, Yi Zhao. Theoretical insight into the stereometric effect of bisPC71BM on polymer cell performance. Science Bulletin, 2016, 61(2): 139-147:
