Abstract:
The JEOL InTouchScopeTM SEM, a touchscreen-controlled analytical, portable low vacuum Scanning Electron Microscope, has been recognized by the editors of R&D Magazine as one of the 100 most technologically significant products introduced into the marketplace over the past year.

JEOL InTouchScope Scanning Electron Microscope Wins R&D 100 Award

Peabody, MA | Posted on June 30th, 2011

"This is a significant honor for JEOL because the InTouchScope is the first SEM to combine the convenience of multi-touch screen operation, analytical versatility, and ease of use in a very portable, small electron microscope. We're delighted that it has become a very popular product and that it has been recognized with this prestigious award," said Donna Guarrera, SEM Product Manager at JEOL USA.

Introduced in September 2010, the InTouchScope has been selected by microscopy labs throughout the U.S. for a variety of routine and research applications. It features integrated Energy Dispersive Spectroscopy (EDS) with the latest Silicon Drift Detector (SDD) technology, automated stage navigation capability, wireless capability, high and low vacuum operation, and a magnification range of 5X - 300,000X. The multi-touch operating screen has the familiar look of today's personal electronic media.

The R&D 100 Awards are a benchmark of excellence for industry sectors as diverse as telecommunications, high-energy physics, software, manufacturing, and biotechnology. Since 1963, the R&D 100 Awards have identified revolutionary technologies newly introduced to the market.

####

About JEOL
JEOL is a world leader in electron optical equipment and instrumentation for high-end scientific and industrial research and development. Core product groups include electron microscopes (SEMs and TEMs), instruments for the semiconductor industry (electron beam lithography and a series of defect review and inspection tools), and analytical instruments including mass spectrometers, NMRs and ESRs.

JEOL USA, Inc., a wholly owned subsidiary of JEOL, Ltd., Japan, was incorporated in the United States in 1962. The company has 13 regional service centers that offer unlimited emergency service and support in the U.S.

For more information, please click here

Contacts:
Patricia Corkum
978-536-2273


JEOL USA, Inc.
11 Dearborn Road
Peabody, MA 01960
978-535-5900
