|BIOIDENT Photonic Flow: The ControlR can be read out via Bluetooth connection using a laptop or PDA (Photo: Business Wire)|
PhotonicFlow System Eliminates the Need for Expensive Readout Systems and Enables Highly Sensitive Multi-Analyte Diagnostics
BIOIDENT Technologies Inc., the leading company in the development of printed optoelectronic solutions for life sciences, today announced the industry's first complete, functional lab-on-a-chip system—the PhotonicFlowTM System. The first application of the PhotonicFlow System announced today is comprised of a multiwell chip, a handheld device controller and readout software. The PhotonicFlow System is based on BIOIDENT's PhotonicLab Platform, which combines printed semiconductors with various lab-on-chip technologies. With this breakthrough technology development, BIOIDENT's customers and partners now have the ability to develop disposable lab-on-a-chip solutions that eliminate the need for expensive and bulky readout systems, enabling cost-effective mobile diagnostics and analysis.
The PhotonicFlow System application unveiled today expands upon BIOIDENT's previously announced nanotiter plate prototype—a 1"x3" multi-well chip with a fully integrated photodetector array based on printed semiconductor technology with a dedicated pixel under each well on the chip. This array converts light into electrical signals, enabling real-time analysis of multiple agents. The new components of the PhotonicFlow System are the handheld device controller for electronic readout of the signals from the photodetector and the readout software for analytics and calibration. This new prototype eliminates the need for large, expensive, external readout systems being used today and opens up new opportunities for applications in medical in-vitro diagnostics, chemical and biological threat detection, and water testing.
"The PhotonicFlow System is a significant milestone for BIOIDENT and for the industry," said Dr. Wasiq Bokhari, CEO for BIOIDENT Technologies. "This system provides our partners a fast path to deliver new point of care tests that are easy to use and cost-effective for end users. By integrating the PhotonicFlow System with their existing devices, assays and reagents, our partners can rapidly develop highly sensitive and multiplexed diagnostics across multiple markets. This is truly a next generation mobile lab that is set to transform current diagnostics and analysis testing across multiple markets."
BIOIDENT's PhotonicLab Platform uses printed semiconductor-based technology to print light detection and electronics capabilities directly onto any surface, including glass and plastic materials, enabling on-chip analysis and diagnostics. In addition, the company uses existing assays and reagents and established testing protocols to deliver real-time and in-situ, multi-parameter detection capabilities for all categories of chemical and biological analytes. BIOIDENT's printing process can also be used to create a wide variety of existing in-vitro diagnostic devices, opening up new opportunities and applications for real-time analysis of chemical and biological substances.
"The combination of NANOIDENT's SEMICONDUCTOR 2.0 Platform technology with our highly specialized, market-specific testing capabilities has resulted in a new PhotonicFlow System that is unique in the market today," said Max Sonnleitner, CTO for BIOIDENT Technologies Inc. "We look forward to working with our partners to develop exciting new applications across the healthcare, water testing and biological and chemical threat detection markets."
BIOIDENT's PhotonicFlow System is available today directly from BIOIDENT for current and future development partners.
For more information about BIOIDENT, the PhotonicFlow System and the PhotonicLab Platform, please visit http://www.bioident.com .
About BIOIDENT Technologies Inc.
BIOIDENT is the technology leader in the development of printed semiconductor-based photonic lab-on-a-chip solutions for the life science market. The company’s core technology utilizes the latest breakthroughs in science and nanotechnology to create the PhotonicLabTM Platform. This platform is used to produce the world’s first disposable photonic lab-on-a-chip solutions for next generation mobile analytics applications such as in-vitro diagnostics, chemical/biological agent detection, and water/food analysis.
BIOIDENT is a subsidiary of Austria-based NANOIDENT Technologies AG.
The company is privately-held with headquarters in Menlo Park, Calif. BIOIDENT leverages NANOIDENT’s SEMICONDUCTOR 2.0TM Platform technology and its high-speed manufacturing process, which uses liquid conductive and semi-conductive materials to print electronic circuits on almost any surface using an inkjet printer.
For more information, please click here
Alissa Vasilevskis or Carmen Pearson, + 1 415-512-0770
BIOIDENT Technologies Inc.
+ 1 650-391-4248
