Home > Press > Imec reports large-area silicon solar cells with high efficiency

Imec’s Cu-plated large-area silicon solar cell with 19.4% efficiency.
Imec’s Cu-plated large-area silicon solar cell with 19.4% efficiency.

Abstract:
At the 25th European Photovoltaic Solar Energy Conference (Valencia, Spain), imec presents several large-area silicon solar cells with a conversion efficiency above 19%. Two types of cells were realized namely with Ag-screenprinted contacts and plated Cu-contacts. Efficiencies of cells with screenprinted contacts were up to 19.1% whereas 19.4% was obtained with Cu-plated contacts. These high efficiencies were obtained thanks to several factors amongst which a combination of improved texturization and optimized firing conditions. The results were achieved on large-area cells (148cm2) with 170µm thickness, proving the industrial viability of the process.

Imec reports large-area silicon solar cells with high efficiency

Leuven, Belgium | Posted on September 7th, 2010

Imec's record efficiency silicon solar cells feature rear-side passivation, laser ablation and, local aluminum back-side field and screenprinted contacts or Cu-plated contacts on advanced emitter schemes. "The fact that such efficiencies can be obtained by metallization schemes based on screenprinted Ag contacts enables compatibility with present industrial metallization practice in the solar cell industry. The Cu-based front-side metallization is a step towards higher sustainability and lower cost, substituting Ag with Cu in future industrial production of crystalline silicon solar cells;" said Dr. Joachim John, team manager industrial solar cells at imec. "These exciting results were obtained in the new solar cell process facilities recently set up in imec."

"High efficiency, low cost, and sustainability are the main drivers in imec's research on crystalline silicon solar cells, eventually targeting cells that are only 40µm thick with efficiencies above 20. We expect further improvements towards efficiencies of up to 20% for large-area silicon solar cells. This achievement is a major step forward towards industrial manufacturing of sustainable, low-cost, thin silicon solar cells with high efficiency," said Dr. Jef Poortmans, director imec energy/solar program.

The results were achieved within imec's silicon solar cell industrial affiliation program (IIAP), a multi-partner R&D program that explores and develops advanced process technologies aiming a sharp reduction in silicon use, whilst increasing cell efficiency and hence further lowering substantially the cost per Watt peak.

####

About imec
Imec performs world-leading research in nanoelectronics. Imec leverages its scientific knowledge with the innovative power of its global partnerships in ICT, healthcare and energy. Imec delivers industry-relevant technology solutions. In a unique high-tech environment, its international top talent is committed to providing the building blocks for a better life in a sustainable society. Imec is headquartered in Leuven, Belgium, and has offices in Belgium, the Netherlands, Taiwan, US, China and Japan. Its staff of more than 1,750 people includes over 550 industrial residents and guest researchers. In 2009, imec's revenue (P&L) was 275 million euro. Further information on imec can be found at www.imec.be.

NOTE: Imec is a registered trademark for the activities of IMEC International (a legal entity set up under Belgian law as a "stichting van openbaar nut”), imec Belgium (IMEC vzw supported by the Flemish Government), imec the Netherlands (Stichting IMEC Nederland, part of Holst Centre which is supported by the Dutch Government), imec Taiwan (IMEC Taiwan Co.) and imec China (IMEC Microelectronics (Shangai) Co. Ltd.).

For more information, please click here

Contacts:
Katrien Marent
Director of External Communications
T: +32 16 28 18 80
Mobile: +32 474 30 28 66


Barbara Kalkis
Maestro Marketing & PR
T: +1 408 996 9975
