Home > Press > Hybrid copper-gold nanoparticles convert CO2--May reduce greenhouse gas emissions

Researchers have combined gold nanoparticles (in light red) with copper nanoparticles (in light green) to form hybrid nanoparticles (dark red), which they turned into powder (foreground) to catalyze carbon dioxide reduction.
Researchers have combined gold nanoparticles (in light red) with copper nanoparticles (in light green) to form hybrid nanoparticles (dark red), which they turned into powder (foreground) to catalyze carbon dioxide reduction.

Abstract:
Copper — the stuff of pennies and tea kettles — is also one of the few metals that can turn carbon dioxide into hydrocarbon fuels with relatively little energy. When fashioned into an electrode and stimulated with voltage, copper acts as a strong catalyst, setting off an electrochemical reaction with carbon dioxide that reduces the greenhouse gas to methane or methanol.

Hybrid copper-gold nanoparticles convert CO2--May reduce greenhouse gas emissions

Cambridge, MA | Posted on April 11th, 2012

Various researchers around the world have studied copper's potential as an energy-efficient means of recycling carbon dioxide emissions in powerplants: Instead of being released into the atmosphere, carbon dioxide would be circulated through a copper catalyst and turned into methane — which could then power the rest of the plant. Such a self-energizing system could vastly reduce greenhouse gas emissions from coal-fired and natural-gas-powered plants.

But copper is temperamental: easily oxidized, as when an old penny turns green. As a result, the metal is unstable, which can significantly slow its reaction with carbon dioxide and produce unwanted byproducts such as carbon monoxide and formic acid.

Now researchers at MIT have come up with a solution that may further reduce the energy needed for copper to convert carbon dioxide, while also making the metal much more stable. The group has engineered tiny nanoparticles of copper mixed with gold, which is resistant to corrosion and oxidation. The researchers observed that just a touch of gold makes copper much more stable. In experiments, they coated electrodes with the hybrid nanoparticles and found that much less energy was needed for these engineered nanoparticles to react with carbon dioxide, compared to nanoparticles of pure copper.

A paper detailing the results will appear in the journal Chemical Communications; the research was funded by the National Science Foundation. Co-author Kimberly Hamad-Schifferli of MIT says the findings point to a potentially energy-efficient means of reducing carbon dioxide emissions from powerplants.

"You normally have to put a lot of energy into converting carbon dioxide into something useful," says Hamad-Schifferli, an associate professor of mechanical engineering and biological engineering. "We demonstrated hybrid copper-gold nanoparticles are much more stable, and have the potential to lower the energy you need for the reaction."

Going small

The team chose to engineer particles at the nanoscale in order to "get more bang for their buck," Hamad-Schifferli says: The smaller the particles, the larger the surface area available for interaction with carbon dioxide molecules. "You could have more sites for the CO2 to come and stick down and get turned into something else," she says.

Hamad-Schifferli worked with Yang Shao-Horn, the Gail E. Kendall Associate Professor of Mechanical Engineering at MIT, postdoc Zichuan Xu and Erica Lai '14. The team settled on gold as a suitable metal to combine with copper mainly because of its known properties. (Researchers have previously combined gold and copper at much larger scales, noting that the combination prevented copper from oxidizing.)

To make the nanoparticles, Hamad-Schifferli and her colleagues mixed salts containing gold into a solution of copper salts. They heated the solution, creating nanoparticles that fused copper with gold. Xu then put the nanoparticles through a series of reactions, turning the solution into a powder that was used to coat a small electrode.

To test the nanoparticles' reactivity, Xu placed the electrode in a beaker of solution and bubbled carbon dioxide into it. He applied a small voltage to the electrode, and measured the resulting current in the solution. The team reasoned that the resulting current would indicate how efficiently the nanoparticles were reacting with the gas: If CO2 molecules were reacting with sites on the electrode — and then releasing to allow other CO2 molecules to react with the same sites — the current would appear as a certain potential was reached, indicating regular "turnover." If the molecules monopolized sites on the electrode, the reaction would slow down, delaying the appearance of the current at the same potential.

The team ultimately found that the potential applied to reach a steady current was much smaller for hybrid copper-gold nanoparticles than for pure copper and gold — an indication that the amount of energy required to run the reaction was much lower than that required when using nanoparticles made of pure copper.

Going forward, Hamad-Schifferli says she hopes to look more closely at the structure of the gold-copper nanoparticles to find an optimal configuration for converting carbon dioxide. So far, the team has demonstrated the effectiveness of nanoparticles composed of one-third gold and two-thirds copper, as well as two-thirds gold and one-third copper.

Hamad-Schifferli acknowledges that coating industrial-scale electrodes partly with gold can get expensive. However, she says, the energy savings and the reuse potential for such electrodes may balance the initial costs.

"It's a tradeoff," Hamad-Schifferli says. "Gold is obviously more expensive than copper. But if it helps you get a product that's more attractive like methane instead of carbon dioxide, and at a lower energy consumption, then it may be worth it. If you could reuse it over and over again, and the durability is higher because of the gold, that's a check in the plus column."

####

For more information, please click here

Contacts:
Caroline McCall
MIT News Office

T: 617-253-1682

Contact:
Sarah McDonnell
MIT News Office

T: 617-253-8923

Copyright © MIT
