Home > Press > New JEOL Large Angle Energy Dispersive Spectrometer (EDS) for Ultrafast Elemental Mapping of S/TEM Samples

Abstract:
JEOL has developed a new generation of Energy Dispersive Spectrometer (EDS) for ultrafast, ultrasensitive collection of X-rays through analysis with its Scanning Transmission Electron Microscopes (S/TEM). Centurio from JEOL is a novel Silicon Drift Detector (SDD) EDS that collects X-rays from samples at an unprecedented large solid angle of up to 0.98 steradians from a detection area of 100mm2. The larger the solid angle of measurement, the more data the EDS collects to construct detailed analytical maps of the elements in the sample.

New JEOL Large Angle Energy Dispersive Spectrometer (EDS) for Ultrafast Elemental Mapping of S/TEM Samples

Peabody, MA | Posted on July 7th, 2011

With the ability to efficiently collect x-rays at very high count rates, Centurio speeds elemental mapping and improves element detection sensitivity without loss of energy resolution. Large pixel number EDS maps can be made at rates ten times faster than with previous EDS designs, with excellent signal-to-noise ratio. Combined with the large probe currents in small probe sizes attainable with aberration-corrected STEM, fast, efficient atomic resolution EDS analysis is possible.



The automatically retractable side entry design allows fast repositioning to avoid irradiation from back-scattered electrons.



Centurio exponentially expands the elemental mapping capability for the JEOL 200kV and higher TEMs, including the JEM-ARM200F atomic resolution TEM with optional cold Field Emission Gun, and the new JEM-2800 automated, high throughput, nano-area analysis TEM.

www.jeolusa.com/PRODUCTS/ElectronOptics/TransmissionElectronMicroscopesTEM/Analytical/Centuriooption/tabid/811/Default.aspx

####

About JEOL USA, Inc.
JEOL is a world leader in electron optical equipment and instrumentation for high-end scientific and industrial research and development. Core product groups include electron microscopes (SEMs and TEMs), instruments for the semiconductor industry (electron beam lithography and a series of defect review and inspection tools), and analytical instruments including mass spectrometers, NMRs and ESRs.

JEOL USA, Inc., a wholly owned subsidiary of JEOL, Ltd., Japan, was incorporated in the United States in 1962. The company has 13 regional service centers that offer unlimited emergency service and support in the U.S.

For more information, please click here

Contacts:
JEOL USA, Inc.
11 Dearborn Road
Peabody, MA 01960
978-535-5900

Patricia Corkum
978-536-2273
